MAKINO A-55 HORIZONTAL MACHINING CENTER
MAKINO A-55 HORIZONTAL MACHINING CENTER
Description
EQUIPPED WITH Through Spindle Coolant Chip Conveyor Coolant Tank Complete Manuals All specifications are subject to verification by purchasing entity.
Specifications
| Manufacturer | Makino |
| Model | A-55 |
| Year | 1992 |
| Condition | Used |
| Serial Number | 299 |
| Travels ( x ) | 22.05 IN |
| Travels ( y ) | 22.05 IN |
| Travels ( z ) | 22.05 IN |
| Pallet size | 15.74 IN x 15.74 IN |
| Pallet load capacity | 882 Lbs |
| Number of pallets | 2 |
| Feed rate, all axis | 315 IPM |
| Spindle taper | CAT #40 |
| Atc | 40 |
| Spindle speed | 12,000 RPM |
| Approximate machine dimensions | 95.66 IN x 137.4 IN |
| Approximate machine height | 111 IN |
| Approximate machine weight | 18,518 lbs |
| Controller | Professional 3 (Fanuc 16) |
