Hwacheon Hi-ECO 21HS Turning Center

Hwacheon Hi-ECO 21HS Turning Center
Available quantity:1
Description
The Hwacheon HI-Eco 21 HS Turning Center is a highly efficient CNC lathe, renowned for its precision and durability in metalworking operations. It is equipped with the advanced Fanuc Korea 18-T CNC Controller, which offers exceptional control and accuracy, enabling operators to perform complex machining tasks with ease. This turning center features a robust construction with a high-speed spindle that ensures optimal machining performance and is ideal for both small and large-scale production environments.
The machine's ergonomic design includes an easily accessible work area, making it user-friendly for operators. The HI-Eco 21 HS also boasts an automatic tool changer that minimizes setup times and maximizes production efficiency. Its integrated cooling system ensures that the machine operates efficiently even under prolonged use, preventing overheating and maintaining the integrity of the workpieces.
This turning center is suitable for a variety of machining applications including turning, threading, and drilling, making it a versatile choice for industries such as automotive, aerospace, and general manufacturing. The Fanuc Korea 18-T controller enhances the machine’s capabilities with its user-friendly interface and powerful programming features, allowing for precise control over all machining parameters.
Overall, the Hwacheon HI-Eco 21 HS Turning Center with Fanuc Korea 18-T CNC Controller represents a superior choice for manufacturers seeking to optimize their machining processes with a reliable, high-performance CNC lathe.
Specifications
Manufacturer | Hwacheon |
Model | Hi-ECO 21HS |
Year | 1997 |
Condition | Used |
Serial Number | M05834509L-04 |
Stock Number | LTH-HWA-944 |
Axis | 2 |
X-Axis Travel | 6.61” |
Z-Axis Travel | 17.32” |
Chuck Size | 8” |
Max. Swing | 22.83” |
Max. Turning Diameter | 11.02” |
Max. Turning Length | 15.74” |
Bar Diameter | 2” |
Spindle Nose | A2-6 |
Spindle Bore | 2.4” |
Spindle Speed | 40-4000 RPM |
Spindle Horsepower (cont./30min.) | 15/20 (a.c.) |
Rapid Traverse X | 1181 IPM |
Rapid Traverse Z | 1181 IPM |
Tailstock Quill Stroke | 3.93” |
Tailstock Quill Diameter | 3.14” |
Tailstock Qill Taper | MT#4 |
Approx. Dimensions | 101”x60.6”x74” |
Approx. Weight | 8900 lbs. |
Equipped With
Fanuc Korea Series 18-T
Tailstock
